Main

• Range: TeSys

• Device short name: LUA1

• Product or component type: Auxiliary contact

Complementary

• Auxiliary contact composition: 1 NO + 1 NC

• Signalling function:

• Fault signalling

• Indicating rotary knob in ready position

• [Ue] rated operational voltage:

• <= 250 V AC

• <= 250 V DC

• [Ui] rated insulation voltage:

• 250 V conforming to CSA

• 250 V conforming to IEC 60947-5-1

• 250 V conforming to UL

• [Ith] conventional free air thermal current: 2.5 A

• Minimum switching voltage: 17 V

• minimum switching current: 5 mA

• Net weight: 0.03 kg

• Connections - terminals: Screw clamp terminals
