Main

• Range: ComPacT

• Product name: ComPacT NSX

• Device short name: NSX100F

• Product or component type: Basic frame

• Device application: Distribution

• Poles description: 4P

• Neutral position: Left

• [In] rated current: 100 A at 40 ℃

• [Ue] rated operational voltage: 690 V AC 50/60 Hz conforming to IEC 60947-2

• Network type: AC

• Network frequency: 50/60 Hz

• Suitability for isolation: Yes conforming to EN/IEC 60947-2

• Utilisation category: Category A

• Breaking capacity:

• 100 kA at 600 V AC 50/60 Hz conforming to UL 508

• 25 kA at 480 V AC 50/60 Hz conforming to UL 508

• 85 kA at 240 V AC 50/60 Hz conforming to UL 508

• 22 kA at 525 V AC 50/60 Hz conforming to IEC 60947-2

• 25 kA at 500 V AC 50/60 Hz conforming to IEC 60947-2

• 35 kA at 400/415 V AC 50/60 Hz conforming to IEC 60947-2

• 36 kA at 440 V AC 50/60 Hz conforming to IEC 60947-2

• 85 kA at 660/690 V AC 50/60 Hz conforming to IEC 60947-2

• 85 kA at 220/240 V AC 50/60 Hz conforming to IEC 60947-2

• Breaking capacity code: F 36 kA 415 V AC

• Control type: Toggle

• Mounting mode: Fixed
